五層教學樓(計算書及CAD建筑圖

文件大小： 6.45 MB
下載次數：
文件評級：
更新時間：2016-12-17
發布人： 649829230

文件下載：

上傳的文件被下載可獲得積分！
積分可下載資料或者提取人民幣！
Ctrl + d 可將本頁面加入收藏夾

文件介紹：
該文件為 rar 格式（源文件可編輯），下載需要 20 積分

五層教學樓(計算書及CAD建筑圖）.rar內容摘要
本設計主要進行了結構方案中橫向框架A，B，C，D軸框架的設計。在確定框架布局之后，先計算了恒載，活載，風載的等效荷載以及各桿端的內力，然后用分層法進行內力分配，然后各層疊加，進而求出在水平荷載作用下的結構內力（彎矩、剪力、軸力）。接著內力組合找出最不利的一組或幾組內力組合。選取最安全的結果計算配筋并繪圖。還進行地基設計。此外還進行了結構方案中的樓梯的設計。完成了平臺板，梯段板，平臺梁等構件的內力和配筋計算及施工圖繪制。
關鍵詞：框架結構設計內力組合

Abstract
The purpose of the design is to do the anti-seismic design in the longitudinal frames of axis A，B，C，D，E，F. When the directions of the frames is determined, firstly the weight of each floor is calculated .Then the vibrate cycle is calculated by utilizing the peak-displacement method, then making the amount of the horizontal seismic force can be got by way of the bottom-shear force method. The seismic force can be assigned according to the shearing stiffness of the frames of the different axis. Then the internal force in the structure under the horizontal loads can be easily calculated. After the determination of the internal force under the dead and live loads, the combination of internal force can be made by using the Excel software, whose purpose is to find one or several sets of the most adverse internal force of the wall limbs and the coterminous girders, which will be the basis of protracting the reinforcing drawings of the components. The design of the stairs is also be approached by calculating the internal force and reinforcing such components as landing slab, step board and landing girder whose shop drawings are completed in the end.
Keywords : frames, structural design, Combine inside the dint ...
